Designed for restaurant sound system and retail shop speaker system installs in Malaysia, this page opens with the 5 speaker set using 6.5 inch wall speakers, with PA amplifier options available for fuller room coverage.
CCF Public Address System
CCF 6.5 inch Wall Speaker PA System 5 Speakers
A PA amplifier and 6.5 inch wall speaker set for shop, factory, broadcast, and restaurant installations. The product images list 6.5 inch wall speaker specifications and separate set combinations from 3 to 16 speakers.
Important Note
6.5 inch wall speaker image shows tweeter + 6.5 inch woofer, 10W, 70-110V.
Speaker image lists sensitivity 90dB and frequency 90-16000Hz.
For long-distance speaker cable or installation matching, contact customer service before ordering.
6.5 Inch Wall SpeakerTweeter + 6.5 inch woofer shown in the product image.
2/3 Zone AmplifierSet images show 2-zone and 3-zone amplifier options.
Clear Benefits
Matched set options: Each set image lists amplifier wattage, speaker quantity, zone type, and suggested area.
Public address use: Images position the set for shop, factory, broadcast, restaurant, and similar spaces.
Multiple inputs: Images show Bluetooth, FM, RCA/AUX, USB, SD card, and microphone inputs.
6.5 Inch Wall Speaker Specifications
Item
Speaker
Driver
Tweeter + 6.5 inch woofer
Power
10 W
Voltage
70-110 V
Size
275 x 200 x 110 mm
Sensitivity
90 dB
Frequency
90-16000 Hz
Set Options Shown in Images
Item
Amplifier + Speakers
Zone / Function
Suggested Area
3 speakers set
60W amplifier x 1 + 10W speaker x 3
2 zones volume
30-60 m2
4 speakers set
80W amplifier x 1 + 10W speaker x 4
2 zones volume
40-80 m2
5 speakers set
80W amplifier x 1 + 10W speaker x 5
2 zones volume
50-100 m2
6 speakers set
80W amplifier x 1 + 10W speaker x 6
2 zones volume
60-120 m2
8 speakers set
100W amplifier x 1 + 10W speaker x 8
3 zones volume with ECHO
80-160 m2
10 speakers set
120W amplifier x 1 + 10W speaker x 10
3 zones volume with ECHO
100-200 m2
12 speakers set
150W amplifier x 1 + 10W speaker x 12
3 zones volume with ECHO
120-240 m2
14 speakers set
180W amplifier x 1 + 10W speaker x 14
3 zones volume with ECHO
140-280 m2
16 speakers set
200W amplifier x 1 + 10W speaker x 16
3 zones volume with ECHO
160-320 m2
Recommended Use
Shop, restaurant, factory, broadcast, school, office, and indoor PA installation.
Connection Reminder
Confirm cable distance, speaker quantity, and amplifier power before installation.
